High Temperature Thermal Solar Steel Structure Precision Engineered For CSP Systems

Brand Name:SUNWAY
Minimum Order Quantity:20 T
Price:USD1000/T-USD1200/T
Payment Terms:L/C,T/T
Supply Ability:100000T/Year
Product Details
Highlight:

Precision Engineered Solar Steel Structure

,

CSP Systems Solar Steel Structure

,

Q355B steel structure for solar panels
Weather Resistance: Yes
Cost: Affordable
Customization Options: Available
Raw Steel Material: Q235B, Q355B, ASTM A36, ASTM572
Application: Steel Structural Building
Color: Optional
Production Capacity: 12500T Per Month
Standard: AISC, ASTM, EN, BS, DIN, GB, JIS
Fire Resistance: Yes
Design: Customized
Durability: High
Surface Treatment: Painting Or Hot-dip Galvanized
Columns And Beam: H Section Column&Beam
Size: Customized
Customizable: Yes
Product Description

High-Temperature Solar Thermal Supports – Precision Engineered for CSP Systems

High Temperature Thermal Solar Steel Structure Precision Engineered For CSP Systems‌‌
Heavy-duty galvanized steel structures engineered for parabolic troughs, heliostats, and receiver towers in utility-scale solar thermal plants.

‌Core Specifications‌

  • ‌Material‌: Zinc-aluminum-magnesium coated steel (S420GD+ZM, 1500h salt spray resistance)
  • ‌Tracking Accuracy‌: ≤0.15° angular deviation (ISO 6286-3)
  • ‌Load Capacity‌:
    • Wind: 75m/s (IEC 61400-2 Class S)
    • Mirror Weight: ≤45kg/㎡ (EN 1991-1-4)
  • ‌Thermal Stability‌: -30°C to +200°C operational range (ASME B31.3)

‌Critical Design Features‌

  • ‌Mirror Precision‌: Laser-aligned mounting surfaces (Ra≤3.2μm)
  • ‌Heat Dissipation‌: Ventilated structural design reduces thermal warping
  • ‌Mass Deployment‌: Pre-assembled torque-tube modules (2MW/day installation rate)
  • ‌Desert Adaptation‌: Sand-erosion resistant coating (ISO 12944 C5-M)

‌Smart Tracking Integration‌

  • Embedded GPS alignment receivers (±2mm positioning)
  • Heat-resistant azimuth drives (IP68 rated)
  • Real-time deflection monitoring via strain gauges

‌Certifications‌

  • SolarPACES Qualified Component
  • AS 1170.2 wind engineering compliance
  • 30-year anti-corrosion warranty

‌Typical Applications‌

  • 100MW+ trough CSP plants with thermal storage
  • Molten salt tower heliostat fields
  • Industrial process heat systems (150-400°C)

Engineered to focus solar energy with millimetric precision.

High Temperature Thermal Solar Steel Structure Precision Engineered For CSP Systems

Product name  High-Temperature Solar Thermal Supports
Material     ASTM; EN; GB;
Surface     Painted; HDG



High Temperature Thermal Solar Steel Structure Precision Engineered For CSP Systems



High Temperature Thermal Solar Steel Structure Precision Engineered For CSP Systems

OEM service available.

A dedicated team of fast response;

EN1090 & AISC & CWB & JIS Certificated Quality;

Full production line for customized products;

Close to Sea port, Convenient for visit and delivery;

150000M2 Manufacturing Area capable to take large volume



High Temperature Thermal Solar Steel Structure Precision Engineered For CSP Systems

High Temperature Thermal Solar Steel Structure Precision Engineered For CSP Systems

High Temperature Thermal Solar Steel Structure Precision Engineered For CSP Systems
